XS SCUBA Thermo Isolation Manifold 7/8″ 14 UNF Inlet Threads 300BAR DIN

$65.99

Thermo – Isolation Manifold – 7/8"-14 UNF Inlet Threads – 300BAR DINTHIS MANIFOLD IS DESIGNED SPECIFICALLY FOR OLDER STEEL HIGH PRESSURE CYLINDERS. THIS IS NOT THE CORRECT MANIFOLD FOR NEWER MODERN HIGH PRESSURE STEEL TANKS.THIS MANIFOLD HAS 7/8"-14 UNF INLET THREADS. IF YOU HAVE ANY QUESTIONS PLEASE REACH OUT.DIN -…

Thermo – Isolation Manifold – 7/8"-14 UNF Inlet Threads – 300BAR DIN

THIS MANIFOLD IS DESIGNED SPECIFICALLY FOR OLDER STEEL HIGH PRESSURE CYLINDERS. THIS IS NOT THE CORRECT MANIFOLD FOR NEWER MODERN HIGH PRESSURE STEEL TANKS.

THIS MANIFOLD HAS 7/8"-14 UNF INLET THREADS. IF YOU HAVE ANY QUESTIONS PLEASE REACH OUT.

DIN – Dedicated 300 bar
Center-to-center distance: 215 mm (8.46?) +/- 5 mm (0.2?)
7/8?-14 UNF standard inlet threads
High gas flow for optimum regulator performance
On/Off seat built from high strength brass with nylon seat and teflon plated for years of smooth operation
One-piece safety assembly protected within the body of the valve
Traditional copper crush washer sealed bonnet
Modular access plugs (R/L) included for use as single valves
Screw-in dip tube with hex tighten feature
Meets the requirements of CGA V9-2009 standards
