Reference class universal additional power source (15V) for record players.
The linear power supply is an important part, significantly improving the sound quality of turntables. Consists of a massive toroidal transformer with shielding between the primary and secondary windings, acting as an isolating transformer, preventing interference from mains power to the audio component.
Features:
- Purest & cleanest power using non-switching power supply (for all Pro-Ject 15V DC turntables)
- NEW Connect it RS – TT 15V MiniXLR – 2.1 power cable included
- Soft start system avoids current inrush in primary winding
- Audio type Toroidal transformer
- Main isolating transformer with copper foil shielding
- Secondary voltage rectification with precise regulation
- High filtration capacity (10,000 µF)
- Low ESR capacitors
- Low noise components with surge protection
- Available in silver or black
Technical specifications:
- Input voltage AC 230 V/50 Hz IEC C15 connector
- Output voltage/current: 15 V/3 A max. (for all Pro-Ject 15 V DC turntables)
- Filtration capacity: 10,000 µF
- Output voltage: ripple rejection better than 75 dB
- Dimensions (W x H x D): 201 x 72 x 195 mm
- Weight: 4800 g
