Long Reach Shackle 5 8″ Bolt Type WLL 3.5 Ton Clevis D Ring Lifting Attachment

5/8″ Alloy Bolt Type Long Reach Shackle – X100 Alloy
Achieve exceptional strength and dependability with the 5/8″ Alloy Bolt Type Long Reach Shackle. Designed for rigorous rigging and lifting applications, this heavy-duty shackle is made from premium G100 Alloy for superior durability and safety.
Key Features:
Material: High-quality X100 Alloy for unmatched reliability and performance.
Finish: Hot-dipped galvanized for corrosion resistance, with a fluorescent orange powder coating (RAL #2007) for enhanced visibility.
Markings: Clearly stamped with ‘X100’, fractional size (5/8″), and Working Load Limit (W.L.L. 3-1/2 T-A).
Dimensions:
Body Diameter: 0.63″
Pin Diameter: 0.75″
Inside Dimensions: 4.00″ Length x 2.25″ Width
Load Capacity: Rated for a Working Load Limit (W.L.L.) of 3-1/2 Tons.
Breaking Strength: Minimum Breaking Strength (M.B.S.): 35,000 lbs.
Applications:
This bolt-type shackle is ideal for construction, towing, industrial lifting, and marine operations. Its long-reach design and high visibility make it a preferred choice for secure and efficient rigging.
Specifications:
Feature Details
Material X100 Alloy
Finish Hot-dipped galvanized + Fluorescent Orange Powder Coating (RAL #2007)
Body Diameter 0.63″
Pin Diameter 0.75″
Inside Dimensions 4.00″ Length x 2.25″ Width
W.L.L. 3-1/2 Tons
M.B.S. 35,000 lbs
M9151

USD : 37.95
